Product Name
DF 4560-8
Quality of Material
A6NO1S-T5
Surface Treatment
Hard Anodized
Weight
2.2kg/m
Section Area
996.2mm²
2nd Section Meoment
lx=23.6*10⁴mm⁴, 1y= 39.2*10⁴mm
T-Slot
8
Specification
4000m/m
Color
Silver
Application
Structures of Middle load. Machine Cover Frame. Conveyor Frame.
Cad Drawing(DWG)
DWG
(98824 K)
Cad Drawing(DWF)
DWF
(43241 K)
--> DWF file PLUGIN to view in browser
WHIP3.ZIP (2,785KB)
Download
Product Section
Product Image
Product Image
